FLIR TG297 Industrial High Temp Thermal Camera

The FLIR TG297 is a one-of-a-kind industrial Thermal Camera tool that combines accurate temperature measurement with imaging capabilities up to 1030°C (1886°F). Patented FLIR MSX® (Multispectral Dynamic Imaging) enhancement technology improves image clarity by bringing out visual scene detail across the entire thermal image.

The TG297 high temperature thermal camera is ideal for high-temperature industrial uses such as glass furnaces, furnaces, and forgings as well as manufacturing applications, allowing you to precisely target potential faults, correct troubleshooting, and monitoring processes. Record footage to assure your team that machines and systems are operating safely and at peak performance.

FLIR TG-297 Industrial High Temp Thermal Camera

FLIR TG-297 Industrial Environments

The FLIRTG297 high temp camera is ruggedly built to withstand harsh industrial environments and is IP54 rated for protection against dust and water. flir high temperature camera also includes a rechargeable battery that can provide up to five hours of continuous operation.

Key features of the FLIR TG-297 include:

• High-temperature range: The TG297 can measure temperatures up to 1030 °C, making it suitable for use in high-temperature applications such as foundries, steel mills, and glass manufacturing.
• Laser pointer: The built-in laser pointer helps the user to aim at the area to be measured, ensuring higher accuracy.
• Image and video capture: The TG297 can capture both images and videos, allowing the user to document and share their results with colleagues and customers.
• Bluetooth connectivity: The camera can be connected to a smartphone or tablet via Bluetooth, allowing the user to easily share images and data.
• Rugged design: The TG297 is designed for use in harsh industrial environments and features rugged housing that can withstand drops, dust, and water.

for the flir tg297 datasheet click on the datasheet tab and for the flir tg297 user manual pdf click on the user manual tab. Also to buy FLIR TG-297 and similar Flir products please contact us.

if you are looking for a similar product visit FLIR E76 and FLIR E96.

FLIR TG 297 Industrial High Temp Thermal Camera Specifications:

• IR resolution: 160 × 120 pixels
• Digital image enhancement:  Yes
• Thermal sensitivity/NETD: <70 mK
• Field of view (FOV): 57° × 44°
• Minimum focus distance: 0.3 m (0.98 ft)
• Distance to spot ratio: 30:1
• Image frequency: 8.7 Hz
• Focus: Fixed
• Focal plane array/spectral range: Uncooled microbolometer/7.5–14 µm
• Detector pitch: 12 μm
• Display resolution: 320 × 240 pixels
• Screen size: 2.4 in. portrait
• Color palettes: Iron, Rainbow, White hot, Black hot, Arctic, Lava
• Image adjustment: Automatic
• Image modes: MSX® (Multi-Spectral Dynamic Imaging)Visual with temperature reading
• Gallery: Yes
