Testo 410 i – Vane Anemometer With Smartphone Operation

Order-Nr. 0560 1410

the Testo 410i vane anemometer is ideal for measuring air velocity and temperature at air outlets and ventilation grilles. Even measuring and adjusting the volume flow is easy. The Testo 410i gives you huge flexibility, so you can adapt to any unplanned measuring requirements in your everyday work.

The Testo 410i combines professional Testo measuring technology with the efficient functions of an App. Your smartphone or tablet is used as a convenient display for your measuring values on-site. You can view all measurement data via the Testo Smart App, and email the log immediately as a PDF or Excel file.

Configuration of the volume flow measurement is really easy with the App, partly due to the fact that you can carry out parametrization of the outlet (dimension, geometry) intuitively. Particularly useful: when adjusting a ventilation system, volume flows of multiple outlets can be cross-checked and compared. Timed and multi-point mean calculation also gives you a quick indication of the average air velocity, for example at a ventilation grille.

System requirements:

• iOS 11 or later
• Android 6.0 or later
• Bluetooth 4.0

Testo 410 i – Vane Anemometer With Smartphone Operation

• Order-Nr.  0560 1410
• Temperature – NTC
• Measuring range: -20 to +60 °C
• Accuracy: ±0.5 °C
• Resolution: 0.1 °C
• Velocity – Vane
• Measuring range: 0.4 to 30 m/s
• Accuracy : ±(0.2 m/s + 2 % of mv) (0.4 to 20 m/s)
• Resolution: 0.1 m/s
• General technical data
• Weight: 117.8 g
• Dimensions : 154 x 43 x 21 mm
• Operating temperature: -20 to +50 °C
• Product-/housing Material: Plastic
• System requirements: requires iOS 11.0 or newer; requires Android 6.0 or newer; requires mobile end device with Bluetooth 4.0
• Product color: black/orange
• Battery type : 3 AAA micro batteries
• Battery life: 130 h
• Diameter vane : 30 mm
• Storage temperature: -20 to +60 °C
