PCE-DT 50 Handheld Tachometer

For rapid speed control, the pistol gauge PCE-DT 50 is the best option. This portable tachometer measures the rate of rotation of rotating components including shafts, drives, pinions, etc.

The light-dark contrast of the reflected light is detected by a receiving diode in the hand tachometer, which employs a laser to emit light. The hand tachometer monitors speeds between 2.5 and 99,999 revolutions per minute (RPM). The speed is shown on the illuminated display of the tachometer. The measuring distance from the hand tachometer is 50 … 500 mm / 2 … 19.7 in.

A manual measuring mode and an automatic measuring mode are both available for the handheld tachometer. The hand tachometer measures when the trigger is depressed in manual measuring mode.

It is measured while in automatic mode till the automated mode is terminated. The hand tachometer has a MAX, MIN, and AVG option for additional analysis of the measured numbers. This mode computes the highest, minimum, and average readings automatically.

To buy PCE DT 50 you can order it online or contact our sales experts.MME is the distributor of PCE products in Dubai, offering the best prices and quality.

more information

MME-AE is a renowned importer and distributor of pce instruments in Dubai and various other countries, providing the most competitive prices in the market. For purchasing PCE DT 50 and obtaining detailed about  Pce dt 50 handheld tachometer price, we encourage you to get in touch with our knowledgeable experts at MME-AE.

PCE-DT50 Features

• Measuring range up to 99,999 rpm
• Automatic mode
• MIN / MAX / AVG mode
• LD display with lighting
• Data hold function
• Automatic shutdown

PCE-DT 50 Specifications

• Measuring range: 2.5 … 99,999 rpm (RPM)
• Measurement accuracy: ± 0.02% + 1 digit
• Resolution: 2.5 … 999 rpm: 0.1 rpm,1000 … 99,999 rpm: 1 rpm
• Measuring distance:50 … 500 mm / 2 … 19.7 in
• Measuring rate:0.5s (over 120 rpm)
• Storage:60 individual data storage
• Automatic shutdown: After 20 s
• Power supply: 9V block battery
• Operating conditions:0 … 50°C / 32 … 122°F, 10 … 90% RH
• Storage conditions:-10 … 60°C / 14 … 140°F, 10 … 75% RH
• Dimensions: 145 x 90 x 35 mm / 5.7 x 3.5 x 1.4 in
• Weight: Approx. 120 g / < 1 lb incl. battery

Accessories

• Roll of Reflective Tape REFB
