PCE DRB 1 Brix Refractometer

A digital tool for determining the amount of sugar in liquids, including fruit juices, soft drinks, wine, honey, and more is the PCE DRB 1 Brix Refractometer. It is intended to deliver findings that are accurate and trustworthy quickly and simply.

The Brix value of the liquid sample is displayed on the color LCD display and high-quality optical sensor of the PCE DRB 1 Brix Refractometer. The instrument also displays the sample’s temperature and automatically adjusts for it. The device’s internal memory can hold up to 100 readings, which may then be transferred by USB to a PC.

Operating and using the PCE DRB 1 Brix Refractometer is simple. It offers an easy-to-use UI that makes measurements rapid and practical. Its waterproof and dustproof construction also makes it appropriate for usage both inside and outside. A calibration solution, a pipette, a cleaning cloth, a software CD, and a USB cable are included with the instrument.

For a variety of sectors and applications, including food and beverage, agriculture, brewing, winemaking, beekeeping, and more, the PCE DRB 1 Brix Refractometer is appropriate. It can assist you in maintaining product quality, streamlining your production procedures, and guaranteeing client happiness.

The PCE DRB 1 Brix Refractometer is the ideal option for you if you’re looking for a digital and portable refractometer that can measure the sugar concentration of liquids with great precision and dependability. Order yours right away to take advantage of accurate and simple Brix measurements.

Features

•  Measurement parameters: Brix, refractive index, temperature
•  Automatic temperature compensation (ATC) from +10 … +40 °C / +50 … +104 °F
•  Handheld and portable
•  User-friendly 3-button operation
•  Fast and precise measuring results in approx. 1 sec.
• ABS plastic housing with IP65 ingress protection rating against water and dust
•  Large, easy-to-read digital LCD shows both the measured value and the temperature
•  The average function measures the same sample 15 times and displays the mean value
•  The stainless-steel ring on the sample well protects the glass prism from damage
•  The internal light source for improved accuracy
• A small liquid sample size of just 4 to 5 drops
•  Easy calibration with distilled water
•  Battery-saving automatic power off after 1 min. of inactivity

PCE DRB 1 Brix Refractometer Specifications

• Temperature compensation automatic       +10 … +40 °C / +50 … +104 °F
• Measurement speed ca. 1 sec.
• Sample size                                                        4 … 5 drops of liquid
• Sample plate                                                     Stainless steel ring with glass prism
• Housing                                                             ABS, IP 65
• Battery                                                                1 x 1.5 V AAA
• Automatic shutdown                                     after 1 min measurement break
• Protection                                                         IP 65
• Dimensions                                                    121 x 58 x 25 mm / 4.76 x 2.28 x 0.98″
• Weight                                                              90 g / 0.2 lb without battery
• Measuring range
  Sugar content                                                  0 … 90 % Brix
  Refractive                                                         index 1,3330 … 1,5177 nD
  Temperature                                                   0 … 40 °C / +32 … +104 °F
• Resolution
  Sugar content                                                      0.1 % Brix
  Refractive index                                                 0.0001 nD
  Temperature                                                      0.1 °C / 32 °F
• Accuracy
  Sugar content                                                    0.2 % Brix
  Refractive index                                                0.0003 nD
  Temperature                                                    ±0.5 °C / +31 … +33 °F
