DEEPSEA DSE2131 Control Module High Quality

The DSE2131 Ratiometric Input Expansion module is used in conjunction with supported DSENet controllers to provide additional, flexible, input
functionality. The module’s ID switch is configurable from the module and the 10 inputs can be configured from within the ‘host controller’. The ratiometric inputs can be configured in a number of ways to connect to digital switches, resistive sensors, 0-10 V DC signals or 4-20 mA signals

DEEPSEA DSE2131 Control Module specifications:

• OVERALL SIZE:1 65 mm x 76 mm x 49 mm (6.5” x 3.0” x 1.9”)
• WEIGHT: 0.22kg
• PRODUCT VARIANTS: 2131-01 – 2131 Ratiometric Input Expansion Module
• CONTINUOUS VOLTAGE RATING: 8V to 35V continuous
• CRANKING DROPOUTS: Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries. LEDs will not be maintained during cranking.
• MAXIMUM OPERATING CURRENT: 292 mA at 12 V, 167 mA at 24 V
  MAXIMUM STANDBY CURRENT: 101 mA at 12 V, 66 mA at 24 V
• INPUTS: 10 inputs configurable for digital/resistive (3k ohms) 4-20 mA and 0-10 V DC
